2/3 Axle 45FT 40FT 65/60t Skeletal/Skeleton Container Trailer for Promotion

2/3 Axle 45FT 40FT 65/60t Skeletal/Skeleton Container Trailer for Promotion

Trailer, Semi Trailer, Truck Trailer manufacturer / supplier in China, offering 2/3 Axle 45FT 40FT 65/60t Skeletal/Skeleton Container Trailer for Promotion, Direct Factory Price 3 Axle Fence/Side Wall Stake Enclosed Cargo Trailer for Sale, 20000liters 6compartments Sinotruck 6*4 Carbon Steel Fuel/Oil Tanker Truck and so on.

Product Details

                                   Should you're interested in it, welcome to buy the quality and durable 2/3 axle 45ft 40ft 65/60t skeletal/skeleton container trailer for promotion with competitive price from us. As one of the leading trailer manufacturers with over 20 years experience, we won't let you down.

Basic Info

  • Load Capacity: 50T

  • Wheel Base: 7000-8000mm

  • Impeller Type: Closed Type

  • Universal Joint Type: Flexible Universal Joint

  • Towing Pin Type: Mushroom Type

  • Differential Gear Type: Gear Type

  • Connecting Type: Semi-trailer

  • Axle Number: 2

  • Self-dumping: Not Self-dumping

  • Material: Steel

  • Axle: 13 Ton FWB

  • Leaf Spring: 90width*10pieces*13mm Thickness

  • Electrical System: 24 Volt Electrical System.

  • Suspension: Mechanic


  • Specification: 12450*2480*1410mm(L/W/H)

  • Type: Semitrailer/Semi-Trailer

  • Certification: ISO9001, CCC, ISO/TS16949, SGS

  • Tread: 1820mm

  • Towing Pin Material: Carbon Steel

  • Hook Type: Single

  • Brake Pad Material: Semimetal

  • Towing Pin Diameter: 90mm

  • Independent Suspension Type: Cross Arm Type

  • ABS Anti-lock Braking System: ABS Anti-lock Braking System

  • Condition: New

  • Braking System: 2 Line Air Braking System with Air Tank ,

  • Relay Valve: Relay Valve

  • Landing Gear: Jost C200,Left Side Operation,

  • Kingpin 2": 50/90mm Welded

  • Transport Package: by Bulk Cargo Ship / RO-RO/Container

  • Origin: Mainland of China

Product Description

2/3 Axle 45FT 40FT 2*20FT 65/60T Skeletal/Skeleton Container Trailer for Promotion

Features for this Skeletal Container trailer
*** Our container transport semi trailer acclaimed, excellent cost-effective, high-quality steel structure,attract the world's major land transportation companies widely adopting, variable cross-section main beam structure design reasonably, light weight, high load capacity.
*** Convenient operation, using 12 Container twist locks, which can transport two 20FT heavy-duty containers,or one 20FT container , or one 40/45FT container,full transportation  function.
*** All frame steel structure made of high-strength & high-quality steel, long service life.
*** Secondary blasting surface treatment and superior corrosion paint process, greatly improving the quality of the vehicle, reducing maintenance costs.
OPTIONS:
1-20ft,30ft,40ft,45ft,48ft,50ft container transporting optional with twist locks
2-flatbed or skeleton chassis type
3-Main beam:500mm height,140mm Q345 or T70 hight strong steel
4-Suspension; Rigid, single point or air suspension
5-material of the main beam: Q345
6-Axles number: 2 3 4 axles.
7-Design type; Straight beam
8-Jost landing gear, FUWA axles and Tri-angle tires
9-extendable or sliding type optional


Skeletal/Skeleton container semitrailer in our ware house:

Product Specification:

ItemSkeletal/Skeleton container semi trailer
Rated Load 60000 kg
Tare Weight6650 kg
Wheel Base 8390+1310+1310 (mm)
Tyre Specifications1100R20-18/12R22.5-18
No. Of the Tyres12
Axle BrandFUWA (BPW optional)
No. Of the Axles3
Axle-load 24000 kg
King Pin50#/90#
Landing Leg28ton
Pieces of leaf-spring10
Suspensionindependent stamping steel rigid suspension (or air suspension)
Departure Angle16
Front/Rear Overhang1890 mm
Outside Dimensions (LxWxH) 14000X2480X1650 (mm)
Material of the Main BeamQ345B manganese plates, automatic submerged arc welded
Brake SystemDual line braking system /ABS
Brake Air ChamberSix double chamber
Electrical24V  7 ways(7 wire harness)
ColorAny color will be available
AccessoryOne tooling box with a set of standard trailer tool
Twistlock No12

Application:
1. This series container semi trailers are mainly suitable for the MID/Long distance transportation of containers,this series container semi trailer divides the flatbed&skeleton container type.
2. The capacity is for 50tons  , we can manufacture it according to your needs.
3. The axles can be FUWA / BPW with different tonnages by your need with price differences.
4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension, etc.
5. The loading deck can be concave beams, tire appeared cover, totally flatbed, or extendable.
6. The loading ramps can be rear end designed, or front loading ladders, which can be mechanic spring ladders and hydraulic loading ramps by different needs .


Guarrantee for the parts of the Flatbed trailer:

ITEM NAMEWARRANTYITEM NAMEWARRANTY
MAIN FRAMEFRAME1 YEARRUNNING GEARAXLE6 MONTHS
SUSPENSION6 MONTHSAXLE BEARING3 MONTHS
KING PIN1 YEARWHEEL HUB3 MONTHS
BALANCE ARM3 MONTHSTIRE6 MONTHS
ITEM NAMEWARRANTYITEM NAMEWARRANTY
BRAKING DEVICEBRAKE DRUM3 MONTHSSUPPORT DEVICELANDING GEAR6 MONTHS
BRKE CHAMBER3 MONTHSSPARE WHEEL  CARRIER6 MONTHS
AIR RESERVOIR6 MONTHS
ITEM NAMEWARRANTY
OTHERSLEAF SPRING3 MONTHS
BRAKE CHAMBER DIAPHRAGM3 MONTHS
EMERGENCY RELAY VALVE3 MONTHS
BRAKE SHOE3 MONTHS
RELAY VALVE3 MONTHS
